40 tph Coal Fired Boiler in Pakistan

June 24, 2020

In terms of use, 40 tons of coal-fired boilers are steam boilers and hot water boilers. Steam boilers are mostly used for steam supply and high-temperature sterilization, etc. 40 tons of coal-fired hot water boilers are mostly used for heating and hot water supply; from the boiler category On the top, there are circulating fluidized bed boilers and chain grate boilers.

40 tph boiler in pakistan

The new scheme of desulfurization and denitration for a 40-ton coal-fired boiler plus desulfurization and denitration equipment is designed. Wet lime desulfurization is used for desulfurization. The flue gas enters the desulfurization tower from the flue gas inlet to the sedimentation and heating chamber, so that the flue gas becomes a high-speed rotating air flow, and alkaline water is sprayed into the high-speed rotating air flow, using the multi-channel reverse spray method invented by our company to make the water The gas is fully contacted, the flue gas reaches the bottom of the dedusting desulfurization cylinder, and then spirally dewaters through the water cylinder to prevent the flue gas from carrying water into the boiler fan. After dehydration, the flue gas returns to the heating chamber and exchanges heat with the high-temperature flue gas before dedusting and desulfurization, and then reheats the flue gas after dedusting and desulfurization, thereby effectively solving the problems of corrosion, dust and vibration caused by the low-temperature and humid flue gas induced draft fan . The desulfurization efficiency can reach more than 95%. No scaling and clogging will occur in the dust removal and desulfurization device, which can effectively reduce the system maintenance workload.

Model of 40 tons coal-fired hot water boiler


Thermal Power (MW) Working Pressure (MPA) Output Water Temperature () Inlet Water Temperature ()


29 1.25 130 70
SZL29-1.0/115/70-All 29 1.0 115


DHL29-1.25/130/70-AⅡ 29 1.25 130


Calculation formula of coal consumption of coal-fired boilers: coal consumption per hour of boiler = boiler thermal power * 3600/coal combustion value/boiler efficiency
The conversion of a 40-ton coal-fired boiler to a thermal power of 28 MW, the heating value of bituminous coal is generally between 27170 and 37200 kj/kg. We take the intermediate value of 22.3 MJ/kg to calculate. The thermal efficiency of a 40-ton coal-fired boiler is about 82%. Formula: 28MW*3600/22.3MJ/82%=5512.4KG.

ZOZEN Boiler has a powerful boiler R&D team and built a complete R&D system. According to the actual needs of users, design a suitable boiler system program for them. Since its development, ZOZEN Boiler has established service centers in Pakistan, Australia, Indonesia, Uzbekistan and other regions to ensure that it provides customers with all-round high-quality services such as project technical consultation, program production, and installation guidance.
